TYPICAL
PHYSICAL PROPERTIES OF SOME MATERIALS
|
|
Ultimate Strength |
|
|
|
|
|
|
Material |
kg/m3 |
Tension MPa |
Comp. MPa |
Strength |
Elasticity |
ratio |
Thermal Exp. |
Conductivity |
Aluminum 2014-T6 |
2800 |
470 |
|
410 |
72 |
0.33 |
23 |
210 |
(alloy)
6061-T6 |
2800 |
228 |
|
131 |
70 |
0.33 |
23 |
210 |
|
|
|
|
|
|
|
|
|
Brass cold rolled |
8470 |
540 |
|
420 |
105 |
0.35 |
19 |
105 |
annealed |
8470 |
330 |
|
100 |
105 |
0.35 |
19 |
105 |
|
|
|
|
|
|
|
|
|
Bronze Manganese |
8800 |
450 |
|
170 |
100 |
0.34 |
20 |
58 |
|
|
|
|
|
|
|
|
|
Cast Iron |
|
|
|
|
|
|
|
|
Gray |
7200 |
170 |
650 |
|
95 |
0.25 |
12 |
45 |
Malleable |
7200 |
370 |
|
250 |
170 |
0.25 |
12 |
45 |
|
|
|
|
|
|
|
|
|
Concrete |
|
|
|
|
|
|
|
|
Low
strength |
2400 |
2 |
20 |
|
22 |
0.15 |
11 |
1 |
High
strength |
2400 |
3 |
41 |
|
32 |
0.15 |
11 |
1 |
Medium
strength |
2400 |
4 |
62 |
|
40 |
0.15 |
11 |
1 |
|
|
|
|
|
|
|
|
|
Copper hard-drawn |
8900 |
380 |
|
330 |
120 |
0.33 |
17 |
380 |
|
|
|
|
|
|
|
|
|
Glass Silicon |
2400 |
80 |
400 |
|
70 |
0.17 |
8 |
0.8 |
|
|
|
|
|
|
|
|
|
Magnesium 8.5% Al |
1800 |
350 |
|
250 |
45 |
0.35 |
26 |
160 |
|
|
|
|
|
|
|
|
|
Steel |
|
|
|
|
|
|
|
|
0.2%C HR |
7850 |
410 |
|
250 |
200 |
0.30 |
12 |
42 |
0.2%C HR |
7850 |
550 |
|
350 |
200 |
0.30 |
12 |
42 |
0.2%C HR |
7850 |
690 |
|
370 |
200 |
0.30 |
12 |
42 |
0.8%C HR
quenched |
7850 |
830 |
|
700 |
200 |
0.30 |
12 |
42 |
|
|
|
|
|
|
|
|
|
Stainless 302 CR |
7920 |
860 |
|
600 |
194 |
0.30 |
17 |
18 |
|
|
|
|
|
|
|
|
|
Titanium 6% Al 4%V |
4460 |
900 |
|
830 |
110 |
0.34 |
9 |
14 |
|
|
|
|
|
|
|
|
|
Properties vary widely depending on changes in composition, temperature and treatment conditions.
CR = Cold rolled HR = Hot rolled
IMPORTANT
CONSTANTS
Constant |
|
SI Unit |
Absolute zero |
-459.67 °F |
-273.15 °F |
Acceleration of gravity |
32.174 ft/s2 |
9.8066 m/s2 |
Atmospheric pressure |
14.694 psi |
0.10132x106 Pa |
Stefan-Boltzmann constant |
0.1714x10-8 Btu/hr ft2 °R4 where °R
= °F + 459.67 |
5.669x10-8 W/m2 °K4 where °K = °C +
273.15 |
APPROXIMATE
PROPERTIES OF MILD STEEL AT ROOM TEMPERATURE
Quantity |
|
SI Unit |
Conductivity |
28.9
Btu/ft hr °F 2.4 Btu/in hr °F |
50 W/m °C |
Density |
15.13
slug/ft3(lbf s2/ft4) 0.730x10-3 lbf s2/ft4 0.282 lbm/in3 |
7800 kg/m3 |
Elastic modulus |
30x106 psi |
207x109 Pa |
Specific
heat |
0.11 Btu/lbm °F |
460 J/kg °C |
Yield
stress |
30x103 psi |
207x106 Pa |
SI
System – Units
|
|
|
|
||||||
Temperature |
Kelvin |
K |
|
||||||
|
|
|
|
||||||
Length |
meter |
m |
|
||||||
Time |
second |
s |
|
||||||
Mass |
kilogram |
kg |
|
||||||
|
|
|
|
||||||
Force |
newton |
N |
kg·m/s2 |
||||||
Pressure |
pascal |
Pa |
N/m2 |
||||||
Work and energy |
joule |
J |
N·m |
||||||
Power |
watt |
W |
J/s |
||||||
|
|
|
|
||||||
Electric current |
ampere |
A |
|
||||||
Electric charge |
coulomb |
C |
s·A |
||||||
Electric potential |
volt |
V |
W/A |
||||||
Electric resistance |
ohm |
|
V/A |
||||||
Electric conductance |
seimens |
S |
A/V |
||||||
Capacitance |
farad |
F |
C/V |
||||||
Permittivity |
|
|
F/m |
||||||
|
|
|
|
||||||
Magnetic flux |
weber |
Wb |
V·s |
||||||
Magnetic flux density |
tesla |
T |
Wb/m2 |
||||||
Inductance |
henry |
H |
Wb/A |
||||||
Magnetic field |
|
|
A/m |
||||||
Permeability |
|
|
H/m |
||||||
|
|
|
|
||||||
Concentration |
|
|
mol/m3 |
||||||
Frequency |
hertz |
Hz |
cycle/s |
||||||
|
|||||||||
Common SI Prefixes |
|||||||||
Tera |
T |
1012 |
|
milli |
m |
10-3 |
|||
Giga |
G |
109 |
|
micro |
|
10-6 |
|||
Mega |
M |
106 |
|
nano |
n |
10-9 |
|||
Kilo |
k |
103 |
|
pico |
p |
10-12 |
|||
Constants
|
Symbol |
|
|
|
|
|
|
|
Electron charge |
e0 |
1.602 x 10-19 C |
Electron mass |
me |
9.1091 x 10-31 kg |
Bohr magneton |
|
9.273 x 10-24 J/K |
Boltzmann constant |
k |
|
Avogadro’s number |
Nav |
|
Gas constant |
R |
8.314 J/(mol K) |
Faraday’s constant |
F |
9.6485 x 104 C/mol |
Permeability of free space |
|
4 x 10-7 H/m |
Permittivity of free space |
|
8.854 x 10-12 F/m |
Characteristic impedance of free space |
z0 |
377 |
Speed of light in vacuum |
c0 |
2.998 x 10-8 m/s |
Atmospheric pressure |
patm |
101.325 kPa |
Zero degrees Celsius |
0°C |
273.15 K |
Gravitational constant |
G |
6.673 x 10-11 N·m2/kg2 |
|
|
|
Notes:
· 1Å = 1 ångström = 10-10 m
· Avogadro’s number is the number of elementary entities in one mole. The elementary entity must be specified; it may be atoms, molecules, ions, electrons or other particles. Values found for Avogadro’s number range within 1% of the listed value.
· Relationships between constants: .
USEFUL RELATIONSHIPS AMONG
ISOTROPIC
ELASTIC CONSTANTS
Also Useful
Are
Constant Names
Lame's constants
Shear modulus
Bulk modulus
Young's modulus
Poisson's ratio
UNITS, CONVERSIONS AND
ABBREVIATIONS
General
Prefixes
10 deka
(da) 10-1 deci (d)
102 hecto (h) 10-2 centi (c)
103 kilo (k) 10-3 milli (m)
106 mega (M) 10-6 micro (m)
109 giga (G) 10-9 nano (n)
1012 tera (T) 10-12 pico (p)
1015 peta (P) 10-15 femto (f)
1018 exa (E) 10-18 atto (a)
Length
1 meter (m) = 100
centimeters (cm) = 3.281 feet (ft) = 39.37 inches (in)
1 mile = 5280 ft = 1.609
kilometers (km)
1 micron (m) = 10-6 m
1 angstrom (Å) = 10-10 m
Area
1 hectare (ha) = 104 square meters (m2) = 2.47 acres
1 acre = 43,560 square feet
(ft2)
1 barn (b) = 10-24 cm2
Volume
1 cubic meter (m3) = 1000 liters = 264.2
1 liter (1) = 103 cubic centimeters(cm3 or ml) = 1.057
1 acre foot = 1.234 x 103 m3
1 cord = 128 ft3
1 board foot = 2.36 x 10-3 m3
1 cubic mile = 4.17 cubic
kilometers (km3)
1 barrel of petroleum (bbl)
= 42
Angles
360 degrees (°) = 2p radians
1 degree = 60 minutes (') of
arc
1 minute of arc = 60 seconds
(") of arc
Time
1 year (y or yr) = 3.1536 x 107seconds (s or sec)
= 8.76 x 103 hours (h or hr)
1 day (d) = 8.64 x 104 sec = 1440 minutes (min)
Mass
1 kilogram (kg) = 2.205
pounds (lb)
1 metric ton (tonne or MT) = 103 kilograms (kg)
= 1.102 short tons
= 0.9842 long tons
1 pound (lb) = 16 ounces
avoirdupois (oz) = 453.6 grams (g)
Energy
1 joule (J) = 1 kg m2/sec2
= 107 ergs = 0.2390 calories (cal)
= 9.484 x 10-4 British thermal units (Btu)
= 1 watt-second (Ws)
= 6.242 x 1018 electron volts (eV)
= 1 newton-meter (Nm)
1 kilowat-hour (kWh) = 3.6 x 106 J
= 3414 Btu
1 quad = 1015 Btu = 1.05 x 1018 J
1 Calorie = 1 kilocalorie
(Kcal) = 103 cal
1 therm = 105 Btu
1 foot pound = 1.356 J
1 kiloton of TNT (KT) = 4.2
x 1012 J
Power
1 watt (W) = 1 joule/second
1 horsepower (hp) = 0.746
kilowatts (kW)
Force
1 newton (N) = 1 kg m/sec2 = 105 dynes (dyn)
Pressure
1 pascal = 1 N/m2 = 1 J/m3
1 bar = 105 pascal = 0.9869 atmospheres (atm)
1 atmosphere (atm) = 76 cm of mercury
= 14.7 lb/in2
= 760 torr
Viscosity
1 poise (p) = 1 dyn-sec/cm2 = 0.1 kg/m sec
Permeability
1 Darcy = 10-12 m2
Quantity |
Units /
Conversion |
General |
|
Acceleration |
1
in/s2 = 0.0254 m/s2 |
Area |
1
in2 = 645.16 mm2 |
Density (i) |
1
lbm/in3 = 27679.905 kg/m3 |
(ii) |
1
slug/ft3 = 515.379 kg/m3 |
Force |
1
lb = 4.448 N (N = |
Frequency |
Hz
(hertz = cycle/s) |
Length |
1
in = 0.0254 m; 1 ft = 0.3048 m |
Mass (i) |
1
lbm = 0.45359 kg |
(ii) |
1
slug = 14.594 kg |
Moment |
1
in-lb = 0.1130 N
• m |
Moment of
inertia (area) |
1
in4 = 416231.4 mm4 |
Moment of
inertia (mass) (i) |
1
lbm-in2 = 2.9264 10-4 kg • m2 |
(ii) |
1
slug-in2 = 0.009415 kg • m2 |
Power (i) |
1
in-lb/s = 0.1130 W (watt = J/s) |
(ii) |
1
hp = 0.746 kW (1 hp = 550 ft-lb) |
Pressure |
1
psi = 6894.8 Pa (psi = pounds/in2; Pa = N/m2) |
Stiffness |
1
lb/in = 175.1 N/m |
Stress (i) |
1
psi = 6894.8 Pa |
(ii) |
1
ksi = 6.8948 MPa; 1 MPa = 145.04 psi |
Time |
s (second) |
Velocity |
1
in/s = 0.0254 m/s |
Volume |
1
in3 = 16.3871 10-6m3 |
Work,
energy |
1
in-lb = 0.1130 J (joule = N • m) |
|
|
Heat
Transfer |
|
Convection
coefficient |
1
Btu/h.ft2 °F = 5.6783 W/m2 °C |
Heat |
1
Btu = 1055.06 J (1 Btu = 778.17 ft-lb) |
Heat flux |
1
Btu/h.ft2 = 3.1546 W/m2 |
Specific
heat |
1
Btu/°F = 1899.108 J/°C |
Temperature (i) |
T °F = [(9/5)T + 32] °C |
(ii) |
T °K = T °C + 273.15 (K = kelvin) |
Thermal
conductivity |
1
Btu/h.ft °F = 1.7307 W/m. °C |
|
|
Fluid Flow |
|
Absolute
viscosity |
1
lb.s/ft2 = 478.803 P (poise = g/cm • s) |
Kinematic
viscosity |
1
ft2/s = 929.03 St (stroke = cm2/s) |
|
|
Electric
and Magnetic Fields |
|
Capacitance |
F (farad) |
Charge |
C (coulomb) |
Electric
charge density |
C/m3 |
Electric
potential |
V (volt) |
Inductance |
H (henry) |
Permeability |
H/m |
Permittivity |
F/m |
Scalar
magnetic potential |
A (ampere) |
|
|
FORMAT OF DYNAFLOW OUTPUT
FILES
This Appendix defines the format of files generated by DYNAFLOW. The data may then be read and converted into the form required by a post-processing program.
Each data set starts with a header of the form:
title
which contains up to 80 characters and is the same as the title defined by the command "DEFINE_PROBLEM" (see Sections 2.1 and 2.2).
Each output file is closed by the following data lines:
title
-1
E.1 TAPE90.name: Nodal
Coordinates/Connectivity Data
title
numnp, nsd, ndof, numeg
for node = 1, numnp
node, (x (i, node), i=1, nsd)
end
-1
for neg = 1, numeg
neg, idum, nen, numel, iopt, el_shape, el_name, reg_name
for ne = 1, numel
ne, mat(ne), (ien(i,ne), i=1, nen)
end
end
where:
numnp = number of nodal points
nsd = number of spatial dimensions
ndof = number of degrees of freedom per node
numeg = number of element groups
neg = element group number
nen = number of nodes per element
numel = number of elements
iopt = 0 2d plane analysis
1 1d analysis
2 axisymmetric analysis
3 3d analysis
el_shape = element shape (character string)
el_name = element name (character string)
reg_name = region name (character string)
ne = element number
mat = material number
ien = connectivity list
E.2 TAPE87.name:
Nodal Results
title
ns, io, label, ‘step’, ns
for node = 1, numnp
node, (d(i, node), i=1, ndof)
end
-1
where:
ns = step number
label = ‘displacement’ (io=1)
‘velocity’ (io=2)
‘acceleration’ (io=3)
‘reaction’ (io=4)
‘eigenshape’ (io=5)
E.3 TAPE96.name: Strain
Energy
title
ns, io, ‘field_w’, ‘step’, ns
for ne = 1, numel_tot
ne, neg, energy
end
-1
E.4 TAPE89.name: Field Results
title
for neg = 1, numeg
for ne = i, numel (neg)
ne, (field (i,ne), i=1, ncomp)
end
end
-1
E.5 TAPE88.name: Time Histories
title
nts, ‘time’
(time(i), i=0, nts) (8 values per line)
title
nts, i1, i2, io, neg, label1, label2, label3, i1, label4, neg
(comp(i), i=0, nts)
where:
nts = number of time steps
i1 = node/element number
i2 = component number
label1 = ‘displ.’ for diplacement (io=4)
‘veloc.’ for velocity (io=5)
‘acc.’ for acceleration (io=6)
‘react’ for reaction (io=15)
‘stress’ for solid element (io=1,2,3)
label2 = component name (character string)
label3 = ‘node’ for nodal time history
‘elmnt’ for field time history
label4 = ‘group’ for field time history
neg = group number (for field time history)
Notes . .
