Lower Control Panel

This panel has an alpha-numeric
display with soft-keys that are
defined by logical menus through
which the system is operated.

The Waveform generator controls
include Start, Hold, Finish, and
Reset buttons. An emergency
STOP button is below this set.

Numeric input in response to soft key requests is made from the Keypad or the Rotary knob. Load Protect provides protection against inadvertent specimen overload during the test setup or specimen loading. Event Detectors allow an action to be performed if a specified event occurs. The Remote button passes control to the computer.
