Materials, Properties and Design

· For a plate with a uniformly distributed load the criteria of optimal light/strong performance again change.
· Optimum stiffness comes from maximizing (E/ ρ³).
· Optimum strength requires selection on the basis of (σ_y / ρ²)

After: Ashby and Jones, "Engineering Materials,"Pergamon (1980)
